Plant layout and Piping Design solutions for Petro-Chemical, Chemical, Power and Nuclear industries.

2D and 3D Plant Design Drafting for accuracy and consistency

Using extensive experience with Autocad based 2D/3D software to create models which reduce overall engineering time, maximize resources and efficiencies while reducing field rework.

Design Drafting

Develop PFD's and P&ID's.

Site Layout and Plot Plans.

Equipment Layouts.

Design and detail Piping Arrangements.

Choose and locate Pipe Supports.

Detail Pipe Supports as required.

Produce Piping Isometrics.

VB & Python Customisation

Python scripting for AutoCAD Plant 3D Components, Catalogues and Specs.

Smart drawings using AutoCAD Attributes.

Single and multi-drawing Attribute extraction to and update from Excel or SQL/Access.

Programmatic manipulation of drawing Entities and Attributes.

3D Model Design

Develop Piping Models.

Develop Equipment Models.

Develop Structural Models.

Extract BOM's & Valve List.

Model Visualization.

Client model reviews.

Project Database Administration.
